Configuration
Connector
2.4 mm Female
Probe Tip
Nickel alloy,Gold Plated
Tips width
30μm
Body
Aluminum Alloy
Tip Configuration
GSG
Insulation
PEEK
Overtravel
50-75μm
Electrical Specifications
Impedance
50Ω
Frequency Range
DC to 50GHz
VSWR
＞14dB, @ 50GHz
Insertion Loss
＜0.8dB@50GHz
Contact resistance
≤ 50mΩ
Environment Data
Working Temperature
-40℃ ~ +85℃
